End of Life Notice
* Effective Date: 2025/04/03
» Support one GbE LAN by RTL8111E
» Compliant with PCI Express Mini specification 1.2
Hardware Spec.
| Form Factor | |
|---|---|
| Form Factor | PCI Express Mini Card |
| Physical Characteristics | |
| Dimensions (LxWxH) (mm) | 51 X 30 |
| Net Weight | 70g |
| Environment | |
| Operating Temperature | 0°C ~ 60°C |
| Storage Temperature | -10°C ~ 70°C |
| Humidity | 5% ~95%, non-condensing |
| Certifications | |
| Safety & EMC | CE/FCC compliant |
| Card Slot Interface | |
| PCIe | Mini card |
Ordering Information
| MPCIE-LAN-R10 | PCI Express Mini GbE LAN module, full size, RoHS |
|---|
