End of Life Notice
* Effective Date: 2020/02/18
» High efficiency
» Low ripple & noise
» Output overvoltage protection
» Short circuit protection on all output
» 100% burn-in under high ambient temperature (50¢XC)
» Vacuum-impregnated transformer
» MTBF: 100K hours at 25¢XC
» 100% Hi-pot tested
» Line input fuse protection
Hardware Spec.
| General | |
|---|---|
| Dimensions | 198 x 97 x 39 |
| Efficiency | 75% |
| MTBF | 100,000 |
| Operating temperature | 0°C ~ 50°C |
| Output Connector |
20+4-pin ATX, 4-pin 12 V CPU, FDD, SATA, 2 x HDD |
| Storage temperature | -20°C ~ 85°C |
| Watt | 200W |
| Input | |
| Voltage | 19 ~ -32 VDC |
| Output | |
| Voltage | +3.3V/12A,+5V/12A,+12V/15.4A,-12V/0.5A,+5Vsb/2A |
Ordering Information
| ACE-4520C-RS | 200W 24VDC ATX INPUT POWER SUPPLY.CCL;RoHS |
|---|
