End of Life Notice
* Effective Date: 2017/10/16
» Wide input range: 6-30 VDC
» Smart system on/off control
» Six selectable power on/off timing modes
» Load down protection
» Over voltage protection
» Short circuit protection
» Over current protection
» Battery voltage monitor
» Amplifier on-delay control
» RoHS compliant
» Compact size
» Infrared remote off (optional)
Hardware Spec.
| General | |
|---|---|
| Dimensions | 45 x 160 |
| Efficiency | 90% |
| Operating temperature | -20ºC ~ 85ºC |
| Storage temperature | -25ºC ~ 90ºC |
| Watt | 140W |
| Input | |
| Voltage | 6 VDC to 30 VDC |
| Output | |
| Voltage |
5 V@10 A, 3.3 V@10 A, 12 V@4 A, -12 V@0.15 A & 5VSB@1.5 A |
Ordering Information
| IDDV-6304140A-R10 | 140W DC/DC 6-30V DC input,Vehicle Converter Module,RoHS |
|---|
