• 4 x Broadcom BCM5720
• 8 ports RJ-45 connector
• 4 PCIe 2.0 x2
• RoHS compliant
Hardware Spec.
| Physical Characteristics | |
|---|---|
| Dimensions (LxWxH) (mm) | 165.50 (L) x 77.8 (W) x 44.2 (H) |
| I/O Interface | |
| Ethernet | 8 x LAN (RJ-45) |
| Environment | |
| Operating Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
| Storage Temperature | -20°C ~ 75°C (-4°F ~ 167°F) |
| Humidity | 5% ~ 90% RH, Non-condensing |
| Certifications | |
| Safety & EMC | RoHS |
| Card Slot Interface | |
| PCIe | 4 PCIe 2.0 x2 |
| Card Features | |
| Speed | 1 GbE |
| Controller Chip | Broadcom BCM5720 |
Ordering Information
| PulM-1G8T-BCM5720-R10 | Broadcom BCM5720 based Network Interface Card with 8 x RJ-45 by 4 PCIe 2.0 x 2 Interface. |
|---|
Package Contents
| Package Content |
|
|---|
