• Unique tray-less and tool-less design
• Support 2.5＂ 9.5mm thickness SATA / SAS HDD and takes one 3.5＂ of PC space
• Lock function for more security
• Patented NSS connector support 50,000 times Hot Swap
Hardware Spec.
| General | |
|---|---|
| Dimensions | 140 x 101.6 x 25 (L x W x H) (mm) |
| Material | |
| Material | Aluminum & SPCC |
| Weight | |
| Weight | 0.236 kg (Gross) |
| Data Transfer Rate | |
| Data Transfer Rate | Up to 6Gb/Sec |
| Drive Bay Space | |
| Drive Bay Space | One 3.5＂ drive bay |
| HDD Type | |
| HDD Type |
2.5” SATA/SAS 1 x HDD/SSD |
| Cooloing Fan | |
| Cooloing Fan | No |
| Hot Swap | |
| Hot Swap | Yes |
| Keylock | |
| Keylock | Yes |
| Signal Out | |
| Signal Out | SATA 7 Pin |
| Color | |
| Color | Black |
| Interface | |
| Interface | SATA 7 + 15 Pin |
Ordering Information
| RHD-101SATA-R20 | DRIVER CAGE;3.5 DEVICE BAY 2.5'' SAS & SATA,R20;RoHS |
|---|
