End of Life Notice
* Effective Date: 2021/12/16
» Wide input range: 9-36 VDC
» AT or ATX mode on/off
» Output voltage protection
» Up to 90% efficiency
» RoHS compliant
» Compact size
Hardware Spec.
| General | |
|---|---|
| Dimensions | 45 x 160 |
| Efficiency | 90% |
| Operating temperature | -20ºC ~ 70ºC |
| Storage temperature | -25ºC ~ 75ºC |
| Watt | 120W |
| Input | |
| Voltage | 9 VDC to 36 VDC |
| Output | |
| Voltage |
12 V@4 A, 5 V@10 A, 3.3 V@8 A, -12 V@0.3 A & 5VSB@2 A |
Ordering Information
| IDD-9364120A-R11 | 120W DC/DC 9~36V input 12V/5V/3.3V/-12V/5VSB output,RoHS |
|---|
